Product Details:
|
| Model Name: | VUF-030-012A5 | Feature: | Constant Voltage LED Driver |
|---|---|---|---|
| Output Power: | 30W | Output Current: | 2.5A |
| Output Voltage: | 12V | Application: | LED Strip Light, Signage |
| Warranty: | 5 Years | Weight: | 300g |
| High Light: | EMC LED Power Supply,30W LED Power Supply,ETL Constant Voltage LED Driver |
||
* Constant voltage output
* IP67 waterproof design
* 100% full load burn-in test
* Over voltage/over load/short circuit/over-temp protection
* Compact dimension design
* Ta:-30℃ ~ +60℃
* Flicker free
* Pass EMC testing
| Item No. | VUF-030-012A5 |
| Output Current | 2.5A |
| Output Voltage | 12V |
| Output Power | 30W |
| Input Voltage | 100-265V |
| Input Frequency | 50/60 Hz |
| Dimension(mm) | L263*W30*H20(mm) |
| Efficiency | 86% |
| Approval | CE RoHS SAA ETL CB UKCA |
Application
Our products are widely used in various industries, such as
1. Indoor LED illuminating lights
2. LED Neon
3. LED urban Decoration
4. LED Lighting Advertising
5. LED Display
6. Safety Protection Apparatus
7. Telecommunications
8. Networks
9. Vehicle Lights, Controller Panels, etc.
Advantage of our Waterproof LED Driver
A. Miniature size with complete protections and light weight
B. Most economical models with complete safety certificates, CE,RoHS.
C.With new CMOS technology, lower products heat, more environmentally friendly and energy saving.
D. Higher efficiency and lower hear dissipations for switched mode power supply.
E. For the Led Lights Strip Power Supply,Widely used in Industrial automation, LED display, communications, etc.
Constant Voltage LED Driver FAQ
Q: Are you manufacturer?
A: Yes, we're Zhuhai factory focus on 12V& 24V LED power supplies(/LED drivers/LED transformers). We have our own import&export license. Welcome to visit us.
Q: What's your advantages of your LED power supplies?
A: Our products use true rating and reliable raw materails (full copper transformers, thermal conductive silicone...) but we quote our customers very competitive prices
Q: What's your payment terms?
A : T/T, L/C, Paypal, Western Union and Trade Assurance on Alibaba.com
30% deposit and balance before shipment or against the copy of B/L (long-term cooperative customers)
Negotiable for our VIP customers.
Q: Do you offer samples for testing?
A: Yes,we can provide free samples for testing and closer inspection,but freight cost should be paid by customers.
Q: OEM/ODM service are available?
A: Yes, we highly welcome OEM&ODM orders.
> Customers' brand logo and model NO. can be print on power label;Laser logo on products' Aluminum/metal casing is available
> User manuals
> Customized color box
> Customized printing carton
> Other stickers stick to LED power supplies or boxes
Q: Do you have burn-in test?
A: All of our LED transformers will have 100% burn-in test for 3~4 hours before packing
Q: Do you provide any certificates for your products?
A: CE,RoHS,SAA basic certifications are always available, some of our products even ETL&CB&UKCA listed. Other certificates, if needed just let us know
Q: What about the warranty for your LED driver?
A: Normally we provide 3 years warranty for our standard products
We can supply 5 years warranty for our high-ending series
