Product Details:
|
| Model Name: | VUF-100-024A01 | Feature: | Constant Voltage LED Driver |
|---|---|---|---|
| Output Power: | 100W | Output Current: | 4.17A |
| Output Voltage: | 24V | Application: | Strip Light, LED Letters |
| Warranty: | 5 Years | Weight: | 500g |
| High Light: | LED Letters EMC LED Driver,lightweight EMC LED Driver,100W Constant Voltage Power Supply |
||
* Wide input Voltage 180~264Vac
* Super thin slim design, with a height of 20mm;
* Protections: short circuit,over load,over voltage;
* IP rating: IP67;
* Ultra-low start up temp.;Working temperature up to 60°C;
* Fan-less design,cooling by free air convection,low noise
* High efficiency,long life,high reliability;
* 100% full load burn-in test;
* CE & RoHS certificated, meet to safety standard and EMC(EN#55032A)
Constant Voltage LED Driver Specification
| Item No. | VUF-100-024A01 |
| Output Current | 4.17A |
| Output Voltage | 24V |
| Output Power | 100W |
| Input Voltage | 100-265V |
| Input Frequency | 50/60 Hz |
| Dimension(mm) | L303*W40*H22(mm) |
| Efficiency | 86% |
| Approval | CE RoHS SAA ETL CB UKCA |
Advantage of our Waterproof LED Driver
A. Miniature size with complete protections and light weight
B. Most economical models with complete safety certificates, CE,RoHS.
C. With new CMOS technology, lower products heat , more environmentally friendly and energy saving.
D. Higher efficiency and lower hear dissipations for switched mode power supply.
E. For the Led Lights Strip Power Supply,Widely used in Industrial automation, LED display, communications, etc.
What Service we can supply?
1. All inquiries will be replied within 24 hours
2. Professional manufacturer,welcom to visit our website
3. OEM/ODM avaliable:
A. Print logo on our product
B. Customized specification
4. After Sales-Service:
A. All products will have 100% burn-in test and strictly quality test before shipping
B. Fast Delivery: 3-7days for samples, 15-20 days for bulk production
5. High efficiency,long life span,reasonable&competetative price,fast lead time;
6. We have our engineer team, if you have any question about your LED applications, let us know freely.
Constant Voltage LED Driver FAQ
Q1: What's Your Main Products?
A: Power Supply,LED Driver,
Q2: Can You Accept OEM Or ODM Orders?
A:Yes, We Can.Customized Orders Are Also Welcomed.
Q3: Where Export Your Products?
A: Our Major Market Is Europe, Australia, North America and Middle East.
Q4: What is Your Delivery Time?
A: Within 15-20 Days After Receiving The Advance (It is According To The Quantity)
Q5: How Do You Control The Items Quality?
A: We Have In Each Production Line, 3 QC Engineers Test Products During Produce
