Product Details:
|
| Model Name: | VHO-200-024B5 | Feature: | Constant Voltage LED Transformer |
|---|---|---|---|
| Output Power: | 200W | Output Current: | 8.33A |
| Output Voltage: | 24V | Application: | LED Strip Light; Sign Light; LED Advertising |
| Warranty: | 3 Years | Weight: | 1210g |
| High Light: | Antiwear Waterproof Electronic LED Driver,Anticorrosive Waterproof Electronic LED Driver,Lightweight IP67 Waterproof LED Driver |
||
* Application: LED Sign, LED Advertising, LED Illumination, etc.
* AC input 100-240V, 50/60Hz
| Item No. | VHO-200-024B5 |
| Output Current | 8.33A |
| Output Voltage | 24V |
| Output Power | 200W |
| Input Voltage | 170-265V |
| Input Frequency | 50/60 Hz |
| Dimension(mm) | L240*W71*H46(mm) |
| Efficiency | 86% |
| Approval | CE RoHS SAA |
VHO-200-012B5 specification.pdf
Waterproof Electronic LED Driver Advantage
1. Safety Standard: Safety: Design by IEC60950 standard.
2. DIELECTRIC STRENGTH Hi-Pot:
Primary to secondary:1200Vac/10mA/60S for type test.
Primary to case:1200Vac/10mA/60S for type test.
3. Insulation resistance:Primary to secondary:10MΩ min at 500V DC.
4. Defective rate is less than 1% in 2 years.
5. 100% full load burn-in test before delivery.
Why Choosing Us?
* Huawei New Energy sole focus on LED drivers and accessories since 2008, which owns an experience R&D team with dozens of patents
* The 20w ultra thin power supply is up to 12mm thickness. We are one of the manufacturers in the world that can produce such thin LED driver in the field of this industry.
* Huawei New Energy can provide customized service and give one stop solution according to different client/application. Such as parameter customization, products consulting/selection and OEM/ODM service.
* Our products are strictly compliant to all major international safety and performance standard. All of our units are 100% tested by a set of rigorous standard control procedures before shipment.
* The products are quite mature and highly recognized by the market. We have already built the sales network in the world thanks to the partners' trust, such as Europe, Australia, US and Southeast Asia etcs.
