Product Details:
|
| Model Name: | VHO-300-024D4 | Feature: | Constant Voltage LED Transformer |
|---|---|---|---|
| Output Power: | 300W | Output Current: | 12.5A |
| Output Voltage: | 24V | Application: | LED Strip Light; Sign Light; LED Display |
| Warranty: | 3 Years | Weight: | 1830g |
| High Light: | Rainproof LED Waterproof Power Supply IP67,300W LED Waterproof Power Supply IP67,Lightweight Waterproof LED Power Supply 12V 30W |
||
Constant voltage output
100% full load burn-in test
Dry, damp and wet location
Over voltage/over load/short circuit/over-temp protection
IP67 waterproof design
Compact dimension design
Ta: -30℃ ~ +60℃
Flicker free
Ultra slim design
| Item No. | VHO-300-024D4 |
| Output Current | 12.5A |
| Output Voltage | 24V |
| Output Power | 300W |
| Input Voltage | 170-265V |
| Input Frequency | 50/60 Hz |
| Dimension(mm) | L275*W95*H50(mm) |
| Efficiency | 85% |
| Approval | CE RoHS SAA |
Advantage
1. Safety Standard: Safety: Design by IEC60950 standard
2. DIELECTRIC STRENGTH Hi-Pot:
Primary to secondary:1200Vac/10mA/60S for type test
Primary to case:1200Vac/10mA/60S for type test
3. Insulation resistance: Primary to secondary:10MΩ min at 500V DC
4. Defective rate is less than 1% in 2 years
5.100% full load burn-in test before delivery
Waterproof Electronic LED Driver FAQ
Q1: What's Your Main Products?
A: Power Supply,LED Driver,
Q2: Can You Accept OEM Or ODM Orders?
A:Yes, We Can.Customized Orders Are Also Welcomed.
Q3: Where Export Your Products?
A: Our Major Market Is Europe, Australia, North America and Middle East.
Q4: What is Your Delivery Time?
A: Within 15-20 Days After Receiving The Advance (It is According To The Quantity)
Q5: How Do You Control The Items Quality?
A: We Have In Each Production Line, 3 QC Engineers Test Products During Produce
