Product Details:
|
| Warranty: | 3 Years | Input Voltage: | 170-265V |
|---|---|---|---|
| Delivery: | DHL,UPS,FEDEX,TNT,by Air And By Sea | Output Power: | 51 - 100W |
| Application: | Led Strip/led Lamp/led Light/mirror Light | Output Current: | 5A |
| Certification: | CE CB ROSH SAA ETL CCC UKCA ERP BIS | Customized Service: | OEM/ODM Label Cable Plug |
| High Light: | Waterproof Plastic LED Driver,Ip65 Plastic LED Driver,Plastic LED Driver 60w |
||
Plastic Housing Power Supply High Quality Waterproof Ip65 Led Light Driver 60w Led Driver
Features
1. Constant Voltage
2. Double insulated Class I Power Supply
3. High Temperature Resistant Flame Retardant Plastic Shell
4. No Flicker, No Noise, Compatible With Various Controllers
5.Over-Voltage, Over-Current,Short-Circuit Protection
Specifications:
| Model | VUO-060-012A5 | |
| Output | DC voltage | 12V |
| Rated current | 5A | |
| Current range | 0~5A | |
| rated power | 60W | |
| Ripple & Noise (peak to peak) | <340mV | |
| No-load voltage | ±0.5V | |
| Input | voltage range | 100~265VAC |
| Current | 47~63Hz | |
| Power factor | 0.5 | |
| effectiveness(Typ.) | 84% | |
| Alternating current(Typ.) | 0.48A/220VAC | |
| Protection | Short circuit | Protection mode: hiccup mode, abnormal conditions can be automatically restored after removal |
| overload | 9A | |
| environment | Operating temperature | -30~+50℃ (Please refer to the load reduction curve) |
| Protection class | IP67 Suitable for outdoor and indoor use | |
| Storage temperature | -40~+80℃ | |
| Safety&EMC | Safety standards | Suitable for EN61347-1;EN61347-2-13;SELV;IP67 |
| WITHSTAND VOLTAGE | I/P-O/P:2KVAC,I/P-FG:2KVAC O/P-FG:0.5KVAC | |
| Tips | 1.If without specia explanation, all specifications are measured at an input of 220VAC, rated load, ambient temperature of 25 ° C . 2.Ripple & Noise Measurement Method: Use a 12 '' twisted pair, and the terminals are connected in parallel with 0.1uF and 47uF capacitors and tested at 20MHz bandwidth. | |
Why choose us?
*All products complete CE,SAA,RoHS,ERP approval, some products have got ETL ,TUV, GS, CB,BIS certificates.
*Made by our own factory, for control the quality also for the LED Driver is stable and reliable.
* Focus on the LED Driver research and development, production more than 13years.
*All products are widely used in Domestic government projects not only, but also Office space, Shopping malls, Star hotel, home lights etc. In all over the world.
*OEM, ODM are all welcome, unchanged quality and competitive price.
FAQ
1. Q: What’s your payment term?
A: We accept T/T, L/C, Paypal,Trade Assurance.
2. Q: How ‘s the delivery time?
A: It rests with the quantity you need,2-15 days usually.
3. Q: What’s your standard of package?
A: Normally are cartons,but also we can pack it according to your requirement.
4. Q: Would you accept to use our own logo on products?
A: Yes,we can do OEM,if the quantity can reach MOQ.
5. Q: Where is your shipping port?
A: Zhuhai port & Shenzhen port,as it is near to our factory,other port is also no problem.
6. Q:How about the quality?
A: We have the best professional engineer and strict QA and QC system.
7. Q: Can we be your distributor?
A: We are looking for distributor and agent all over the world for LED drivers/power supply.
8. Q: what's the trade terms you can do?
A: We accept EXW, FOB and CIF.
