Product Details:
|
| Warranty: | 3 Years | Output Frequency: | 47~63HZ |
|---|---|---|---|
| Product Name: | 120vdc Led Driver For LED Floodlight Driver | Output Power: | 120w |
| Input Voltage: | 265V | Output Current: | 5.0A |
| Certification: | CE ROHS CB UKCA | Model Number: | VUF-120-024E1-D |
| High Light: | LED driver for floodlight,230v Strip Light LED Driver,Strip Light LED Driver 120w |
||
Positive And Negative Power Supply Power Cord Driver For 230v Led Strip Light
Strip Light LED Driver Features
* Constant voltage output
Products descriptions
| Model | VUF-150-012E3-D dimmable led driver | ||
| Output | DC voltage | 12V | |
| Rated current | 12.5A | ||
| Current range | 0-10V | ||
| rated power | 150W | ||
| Ripple & Noise (peak to peak) | <200mV | ||
| No-load voltage | ±0.5V | ||
| Input | voltage range | 100~265VAC | |
| Current | 47~63Hz | ||
| Power factor | 0.95 | ||
| effectiveness(Typ.) | 0.82 | ||
| Alternating current(Typ.) | 0.56A/220VAC | ||
| Protection | Short circuit | Protection mode: hiccup mode, abnormal conditions can be automatically restored after removal | |
| overload | 100-112% | ||
| environment | Operating temperature | -30~+50℃ (Please refer to the load reduction curve) | |
| Protection class | IP67 Suitable for indoor and outdoor use | ||
| Storage temperature | -40~+80℃ | ||
| Safety&EMC | Safety standards | Suitable for EN61347-1;EN61347-2-13;SELV;IP67 | |
| Pressure | Input - Output: 3.75KVAC Input - Enclosure, Ground: 2KVAC Output - Enclosure, Ground: 0.5KVAC | ||
| Dimming method | Triple (0 / 1-10Vdc or 10V PWM or resistor) | ||
| Tips | 1.If without specia explanation, all specifications are measured at an input of 220VAC, rated load, ambient temperature of 25 ° C . 2.Ripple & Noise Measurement Method: Use a 12 '' twisted pair, and the terminals are connected in parallel with 0.1uF and 47uF capacitors | ||
Company Profile
Established in 2008,Zhuhai Hualiang Electronics Co.Ltd(Zhuhai Hengqin District Huawei New Energy Co.Ltd) is a high tech company which dedicated in LED Switching Power Supply. We ourseives toR&D,Productionand also After-sale Service.
Our corporate philosophy is“science and education towards production”with an emphasis towards fostering high level talentToday we have more than 120 skilled employees, 40% college graduates and 25%university qraduates.Three of our staff have received senior technical titles and one won the“Outstanding Award for Skilled personnel" of Guangdong province.
FAQ
1. who are we?
We are based in Guangdong, China, start from 2015,sell to Domestic Market(20.00%),Western Europe(16.00%),North America(15.00%),Central America(8.00%),Eastern Europe(6.00%),Southeast Asia(6.00%),South America(6.00%),Northern Europe(5.00%),Africa(5.00%),Southern Europe(4.00%),Eastern Asia(3.00%),South Asia(3.00%),Oceania(3.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Constant Voltage Ultra slim power supply,IP67 Constant Voltage 0-10V dimmable driver,Constant Voltage Ultra slim power supply,IP67 Constant Current led driver,Led Driver
4. why should you buy from us not from other suppliers?
Established in 2008 ,Zhuhai Hualiang Electronics Co.,Ltd(Zhuhai Hengqin District Huawei New Energy Co., Ltd) is a high tech company which dedicated in LED Switching Power Supply. We ourselves to R&D, Production, and also After-sale Service.
5. what services can we provide?
Accepted Delivery Terms: FOB,EXW,Express Delivery；
Accepted Payment Currency: USD,EUR,CNY;
Accepted Payment Type: T/T,PayPal,Western Union,Cash,Escrow;
Language Spoken: English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
