Product Details:
|
| Model Name: | VHO-100-012A01 | Feature: | Constant Voltage Outdoor IP67 |
|---|---|---|---|
| Output Power: | 100W | Output Current: | 8.33A |
| Output Voltage: | 12V | Application: | LED Strip Light; Landscape Light |
| Warranty: | 3 Years | Weight: | 500g |
| Highlight: | Rustproof LED Strip Light Driver,SAA LED Strip Light Driver,Durable 12V Constant Voltage Power Supply |
||
* Application: LED Sign, LED Advertising, LED Illumination, etc.
* AC input 100-240V, 50/60Hz
| Item No. | VHO-100-012A01 |
| Output Current | 8.33A |
| Output Voltage | 12V |
| Output Power | 100W |
| Input Voltage | 170-265V |
| Input Frequency | 50/60 Hz |
| Dimension(mm) | L303*W40*H22(mm) |
| Efficiency | 85% |
| Approval | CE RoHS SAA |
Advantage
1. Safety Standard: Safety: Design by IEC60950 standard
2. DIELECTRIC STRENGTH Hi-Pot:
Primary to secondary:1200Vac/10mA/60S for type test
Primary to case:1200Vac/10mA/60S for type test
3. Iusulation resistance:Primary to secondary:10MΩ min at 500V DC
4. Defective rate is less than 1% in 2 years
5. 100% full load burn-in test before delivery
